2WA/2NJ/2RK-1
8-83
YC4 A04 GND - - Ground
A05 FD_SW I DC0V/3.3V DP original feed sensor: On/Off
A06 +3.3V O DC3.3V DC3.3V power output
A07 GND - - Not used
A08 RGST_SW(V) - - Not used
A09 +3.3V - - Not used
A10 ANODE O DC3.3V DC3.3V power output
A11 GND - - Ground
A12 EXIT_SW(M) I DC0V/3.3V DP eject sensor: On/Off
A13 NC - - Not used
B01 NC - - Not used
B02 +24V O DC24V DC24V power output
B03 LED_REM I DC0V/3.3V LED remote signal
B04 GND - - Not used
B05 GND - - Ground
B06 CCD_TMG_SW I DC0V/3.3V CCD sensor: On/Off
B07 +3.3V O DC3.3V DC3.3V power output
B08 ANODE O DC3.3V DC3.3V power output
B09 GND - - Ground
B10 DP_OPEN I DC0V/3.3V DP open/close sensor: On/Off
B11 ANODE - - Not used
B12 GND - - Not used
B13 SKEW_SW - - Not used
YC5 1 FEED_OUT2B O DC0V/24V(pulse) DP original feed motor control signal
2 FEED_OUT2A O DC0V/24V(pulse) DP original feed motor control signal
3 FEED_OUT1A O DC0V/24V(pulse) DP original feed motor control signal
4 FEED_OUT1B O DC0V/24V(pulse) DP original feed motor control signal
5 RGST_OUT2B O DC0V/24V(pulse) DP registration motor control signal
6 RGST_OUT2A O DC0V/24V(pulse) DP registration motor control signal
7 RGST_OUT1A O DC0V/24V(pulse) DP registration motor control signal
8 RGST_OUT1B O DC0V/24V(pulse) DP registration motor control signal
9 LIFT_OUT2B O DC0V/24V(pulse) DP lift motor control signal
10 LIFT_OUT2A O DC0V/24V(pulse) DP lift motor control signal
11 LIFT_OUT1A O DC0V/24V(pulse) DP lift motor control signal
12 LIFT_OUT1B O DC0V/24V(pulse) DP lift motor control signal
YC6 1 +24V O DC24V DC24V power output
2 GND - - Ground
Connec-
tor
Pin Signal I/O Voltage Description
