2WA/2NJ/2RK
6-114
Contents
Simulate the original conveying operation separately in the DP.
Purpose
Check the DP operation
Method
1.Press the [Start] key.
2.Place an original in the DP if running this simulation with paper.
3.Select the scan speed
Method: Normal Speed/High Speed
1.Select the item to operate.
2.Press the [Start] key.
* :The operation starts.
3.To stop the operation, press the [Stop] key.
Setting: Mode
1.Select the item to set.
2.Press the [Start] key to set the setting value.
Method: Reset
1.Select [Execute].
2.Press the [Start] key to reset.
Method: Result
1.Displays the conveying timing data.
Completion
Press the [Stop] key.
The screen for selecting a maintenance item No. is displayed.
U203 Check DP operation
(Message: Check DP Operation)
Items Contents
Normal Speed Normal scanning (600dpi)
High Speed High speed scanning
Mode Set the conveying timing inspection mode
Reset Reset the conveying timing inspection data
Result Check the conveying timing
Items Contents
CCD ADP With paper, a single-sided original is fed to the CCD
CIS With paper, a double-sided original is fed to the CIS
CCD ADP (Non-P) Without paper, a single-sided original is fed to the CCD (continuous
operation)
CIS(Non-P) Without paper, a double-sided original is fed to the CIS (continuous
operation)
Items Contents
On Set the conveying timing inspection mode to On
Off Set the conveying timing inspection mode to Off
To Next Page
