OPERATION
3. Pull lever (A) and rotate toward header to lower safety
prop (B) onto cylinder. Repeat for opposite cylinder.
Figure 4.
60: Safety Prop
4. To disengage safety props and for storage, turn
lever (A) away from header to raise safety prop
until lever locks into vertical position. Repeat for
opposite cylinder.
Figur
e 4.61: Safety Prop
5. Start engine, choose a level area, and lower header to
the ground. Stop engine and remove key.
169890 118 Revision A
