OPERATOR’S STATION
Display (lower or upper line) Description
##.# HEADER AN
GLE
##.# HEADER SE
NSOR (flashing)
Angle setting
(00.0–10.0) header relative to ground. Optional
9
.
Sensor Disabl
ed.
##.# VOLTS
Engine electrical system operating voltage.
FUEL |■■■■|■■■■| Level of fuel in tank.
ENGINE TEMP
### °F
ENGINE TEMP
### °C (if me tric)
Engine coolant temperature.
SCROLL
SUB-MENU (lower line lnly)
#### KNIFE SPEED
##.# HEADER HEIGHT
##.## ##.# REEL IND
##.# ##.# DRAP INDX
Displays sub-menu after 2–3 seconds. Press SELECT to cancel.
Scroll through sub-menu disp lay with CDM switch.
Optional
9
##.## REEL MIN RPM (lower line)
Reel spee
d drops below programmed set-point.
MINIMUM
(lower line)
Optiona
l
9
Miscellaneous Operational Information
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (upper line) Description
<LEFTTURN■
Indi
cates left turn when left arrow is pressed on CDM.
■ RIGHT TURN > Indicates right turn when right arrow is pressed on CDM.
■ HAZARD ■
Indicates hazard warning lights are ON when hazard button is pressed
on CDM.
RO
AD GEAR
Wi
th High Range selected on Console switch.
HEADER ENGAGED Header drive engaged (engine will not s tart).
CENTER STEERING Center steering wheel and/or GSL not in N-DETENT.
169890 66 Revision A
