2.4 Component Location
Figure 2.
4: Front View
A - Header Lift Leg B - Header Float Springs C - Operator’s Station
D - Windshield Wiper
E - Turn Signal / Hazard Lights F - Field/Road Lights G - Handholds
H-Mirror
J-Door
K - Maintenance Platform L - Center-Link
Figure 2.5: Rear View
A-Ca
ster Wh eel
B - Walking Beam
C-Re
dTailLights
D-En
gine Compartment Hood
E - Flood Lights F - Horn
G - Turn Signal/Hazard Lights
H - Mirror
J-DriveWheel
K-S
wath Lights
