MacDon M105 - Engine Running, Header Engaged, Draper Header, Index Switch off

OPERATOR’S STATION
Display (Lower or Upper Line)
Description
###### TOTAL A
CRES
###### TOTAL H
ECT (if Metric)
Total area cut by machine.
##.## REEL RPM
##.## REEL SENSOR (Flashing)
Reel rotational speed. Optional
7
Sensor disabled.
##.# AUGER SPEED Auger rotational speed (4.7–9.9).
#### KNIFE S
PEED
#### KNIFE
SENSOR (Flashing)
Knife speed
In strokes per minute. Optional
7
.
Sensor dis
abled.
##.# HEADER HEIGHT
##.# HEADER SE NSOR (Flashing)
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor disabled.
##.# HEADER ANGLE
##.# ANGLE SENSOR
Angle setting (00.0–10.0) header relative to ground. Optional
7
.
Sensor disabled.
##.# VOL
TS Engine electrical system operating voltage.
FUEL|■■■■|■■■■| Level of fuel in tank.
ENGINE TEMP ### °F
ENGINE TEMP ### °C (if Metric)
Engine
coolant temperature.
SCROL
L
SUB-M
ENU (Lower Line Only )
#### K
NIFE SPEED
##.#
AUGER SPEED
##.#
# REEL RPM
##.#
HEADER HEIGHT
Displ
ays sub-menu after 2–3 Seconds. Press SELECT to cancel. Scroll
throu
gh sub-menu display with CDM switch.
Knife
speed is optional
7
.
Reel
rpm is optional
7
.
Engine Running, Header Engaged, Draper Header, Index Switch OFF
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (lower or upper line) Description
##
###.# ENGINE HRS Total engine operating time.
#####.# UNIT HRS
Total windrower operating time.
#####.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line,
and hold down program switch until display resets (5–7 seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.## REEL MPH or REEL RPM
##.## REEL KPH (if m etric)
##.## REEL SENSOR (flashing)
Reel peripheral speed in miles per hour or rpm. Optional.
8
.
Sensor Disabled.
##.# DRAPER SPEED Draper speed (0.0–10.0).
7. Optional: Available with Expansion M o dule installation – Wh ole Goods Bundle MD #B4666.
8. Optional: Available with Expansion Module Installation – W h ole Good s Bundle MD #B4666.
169890 64 Revision A
