OPERATOR’S STATION
Engine Running, Header Disengag ed
Scroll th ro ug h display with cab display modu le (CD M) switch or ground speed lever (GSL) switch .
Display (lower or upper line) Description
#####.# ENGI
NE HRS Total engine operating time.
#####.# UNIT HRS
Total windrower operating time.
#####.# HEADER HRS
Total header operating time.
###.# SUB A
CRES
###.# SUB H
ECTARES (if metric)
Area cut si
nce last reset. To reset, display SUB ACRES on lower line,
andholddo
wn Program switch until display resets (5–7 seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.# HEADER HEIGHT Distance setting (00.0–10.0) between cutterbar and ground.
##.# H EA
DER ANGLE
Angle se
tting (00.0–10.0) header relative to ground. Optional.
6
##.# VOLTS
Engine electrical system operating voltage.
FUEL |■■■■|■■■■|
Level of f uel in tank.
NOTE:
When fuel level is low, menu selections will be disrupted.
ENGIN
ETEMP###°F
ENGIN
ETEMP###°C(ifmetric)
Engine coolant temperature.
SCROLL
SUB-MENU (Lower L ine Only)
##.# HEADER HEIGH T
FUEL |■■■■|■■■■|
ENGINE TE MP ### °F
ENGINE TEMP ### °C
Displays above items after 2–3 seconds; press SELECT to cancel.
ROAD GEAR (upper line) Ground speed range switch in H IGH range. Only if 2 selected.
En
gine Running, Header Engaged, Auger Header
Scroll th ro ug h display with cab display modu le (CD M) switch or ground speed lever (GSL) switch .
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
T
otal engine operating time.
#####.# UNIT HRS
Total windrower operating time.
#####.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOU R (if Metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (if Metric)
Area cut since last reset.
6. Optional: Available with installation of Option al Expa n sion Module Installation—Whole Goods Bundle MD #B466 6.
169890 63 Revision A
