OPERATION
4.6 Operating with a D-Series H eader
4.6.1 Configuring Hydraulics
The windrower must be fitted with a draper drive basic kit to operate D-Series draper headers.
Windrowers equipped with D-Series hydraulics have four
header drive hoses on the LH side.
Figure 4 .
170: Draper Header Drive Hydraulics
There are
also up to five reel drive h o se s on the RH sid e.
If necess
ary, obtain the following kit from your MacDon
Dealer.
• Base Kit MD #B55 77 ( Installation instruc tio n MD
#169537 is s upplied with the kit.)
Figure 4.171: Draper Header Reel Hydraulics
169890 167 Revision A
