OPERATOR’S STATION
Display (lower or upper line) Description
#### KNIFE SPE
ED
#### KNIFE SEN
SOR (flashing)
Knife speed In
strokes per minute. Optional.
8
Sensor Disabl
ed.
##.# HEADER HEIGH T
##.# HEADER SENSOR (flashing)
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled.
##.# HEADER ANGLE
##.# HEADER SENSOR (flashing)
Header Angle setting (00.0–10.0) relative to ground. Optional.
8
Sensor Disabled. ANGLE and SENSOR alternate at 1 second intervals.
##.# VOLTS
Engine electrical system operating voltage.
FUEL |■■■■|■■■■| Level of fuel in tank.
ENGINE TE MP ### °F
ENGINE TEMP ### °C (if metric)
Engine co
olant temperature.
SCROLL
SUB-MEN
U (lower lin e only)
#### KNI
FE SPEED
##.# REE
LRPM
##.# DR
APER SPEED
FUEL |■
■■■|■■■■|
Display
s sub-menu after 2–3 seconds. Press SELECT to cancel.
Scroll t
hrough sub-menu display w ith CDM switch.
Optiona
l.
8
KNIFE SPD OVERLOAD (lower line) Knife speed is less than programmed set point.
Engine Running, Header Engaged, Draper Header, Inde x Switch ON
Scro
ll thro ug h dis pla y with cab display modu le (CD M) sw itch or ground speed lever (GS L) switch .
Disp
lay (lower or upper line)
Desc
ription
#####.# ENGINE HRS
Total engine operating time.
#####.# UNIT HRS
Tot
al windrower operating time.
##
###.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line
and hold down program switch until display resets (5–7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.## ##.# REEL IND
##.## REEL.SENSOR (flashing)
Reel peripheral speed along with ground speed in mph or kph.
Optional.
9
Sensor Disabled.
##.# ##.# DRAP INDX Draper speed along with ground speed in mph or kph.
#### KNIFE SPEED
#### KNIFE SENSOR (flashing)
Knife speed in strokes per minute. Optional
9
Sensor Disabled.
##.# HEADER HEIGH T
##.# HEADER SENSOR (flashing)
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled.
9. Optional: Available with Expansion Module installation—Whole Goods bund le MD #B4666.
169890 65 Revision A
