MacDon M105 - Lubricants, Fluids, and System Capacities

MAINTENANCE AN D SERVICING
Lubricants, Fluids, and System Capacities
Table 5.15 System Capacities
Lubricant/Fluid
Location Description
Capacity
Grease
As require d unless
otherwise specified
SAE Multi-Purpose.
High Temperature Extreme Pressure
(EP2) Performance W ith 1%
Max Molybdenum Disulphide
(NLGI Grade 2) Lithium Base.
Diesel fuel
Fuel tank
Diesel Grad
e No.2, or Diesel Grade No.1
and2mix
25
; refer to Fuel Specifications,
page 198 for mo
re information.
97 US gallo n
s
(367 liters
)
Hydraulic oil Hydraulic reservoir
SAE 15W-40 Compliant With SAE Specs
For API Class CJ-4 Engine Oil Which
Meets or Exceeds CES 20081 and API
Performance C lassification CJ-4.
11.5 US gallons
(44 liters)
Gear lubricant
Wheel drive
26
SAE 75W-90, API Service Class GL-5.
Fully Synthetic Gear Lubricant,
(SAE J2360 Preferred).
1.5 US quarts
(1.4 liters)
Antifr
eeze
Engine cooling
system
ASTM D-
6210 and Fleetguard
ES Comp
leat
®
.
6.6 US g
allons
(25 lit
ers)
27
Engine oil Engine oil p an
SAE 15W-40 Compliant With SAE Specs
For API Class SJ and CH-4 Engine Oil.
12.6 US quarts
(11.9 liters)
28
Air co
nditioning
refri
gerant
29
Air co
nditioning
syste
m
R134A 5 lbs (2.27 kg)
Air conditioning
refrigerant oil
30
Air conditioning
system total
capacity
PA G SP-15 8.1 fl. oz. (240 cc)
Receiver drier
(MD #183273)
Air conditioning
system
PA G SP-15 2 fl. oz. (60 cc)
Condenser
(MD #138983)
Air conditioning
system
PA G SP-15 1 fl. oz. (30 cc)
Evaporator
(MD #160130)
Air conditioning
system
PA G SP-15 2 fl. oz. (60 cc)
Ho
ses
Ai
r conditioning
sy
stem
PA G SP-15 1 fl. oz. (30 cc)
25. Optional when op erati ng temperature is below 0°C (32°F).
26. SAE 85W-140 API Service Class GL-5. Extreme Pressure Gear Lubricant is used before initial change.
27. Equal p arts with water, high quality, soft, de-ionized or distilled water as recommended by supplier.
28. Includes filter
29. For prior models who have not upgraded to 5 lbs of refrigerant order Kit MD #183180, which includes high pressu re switch
and decal to advise of system s 5 lbs charge requirement. Refer to Service Bulletin 1254.
30. New compressor (MD #2030 13) comes filled. If installing on 2 014 and prior, refer to Service Bulletin 1254.
169890 199 Revision A
