MAINTENANCE AND SERVICING
Replacing Field Light Bulb
1. Remove two scre ws (A), a nd remove light a ssembly.
2. Replace bulb as described in Replacing Fie ld Lig ht
Bulb, page 270.
Figure 5.1
39: Field Lights
Flood Ligh
ts: Forward
Adjusting Forward Flood Lights
The forward flood lights are NOT adjustable.
Replacing Bulb in Cab-Forward Flood Light
DANGER
Stop engine and remove key from ignition before leaving operator's seat for any reason. A child or even a
pet could engage an idling machine.
Replace bulbs as follows:
1. Shut down engine and remove key. Turn lights OFF.
169890 270 Revision A
