MAINTENANCE AN D SERVICING
2. Hold onto the handholds (A) on the cab front corners
and stand on the header anti-slip strips when removing
the forward field lights.
3. Remove two s crews (B) an d remov e light bezel (C).
4. Remove light from receptacle.
Figure 5.
140: Forward Flood Lights
5. Pinch the wire retainer (A) and lift away from hooks.
6. Remove bulb (B) from body and pull wire from
connector (C).
IMPORTA
NT:
Do NOT to
uch the glass of the halogen bulb as the oils
or othe
r chemicals from your skin will cause the bulb to
fail pr
ematurely.
Figur
e 5.141: Flood Light Assembly
169890
2
71
Revision A
