OPERATOR’S STATION
3.3 Operator’s Seat Adjustments
The operator’s seat has several adjustments. Refer to the following for the location and description of
each adjustment.
A – Armrest Up or Down
• R aise armrest (A) for easier access to the seat.
• Lower armrest (A) after seat belt is buckled.
B – Lumbar Support (Stiffness of Seat B ack)
• R otate knob (B) upward to increase stiffness.
• Rotate knob (B) d ownward to d ecrease stiffness.
C – Angle of Armrest
• Rotate kn o b (C) cloc kwise to in crea se armrest angle.
• R otate knob (C) counterclockwise to decrease angle of
the armrest.
D – Angle of Seat Back
• Pull lever (D) up to release the seat back.
• Position seat back a s desired.
• R elease lever (D) to lock the seat back in position.
E – Seat Fore-Aft Position
• Pull lever (E) up to release the seat for adjustment.
• M ove the seat forward or backward as desired.
• R elease lever (E) to lock the seat in position.
Figure 3.2: Seat Adjustments
A-Armres
t
B - Lumbar Support C - Armrest Angle
D - Seat Back Angle E - Seat Fore-Aft Position
169890 37 Revision A
