OPTIONS AND ATTACHMENTS
7.1.18 Transport D rawbar
The transport
drawbar mounts to the walking beam and allows the M105 to tow MacDon headers equipped with a
slow-speed tr
ansport system. This drawbar is to be used for hitching tow-behind swath rollers only. Requires a
weight box.
MD #B5411
39
Instruction
MD #169420 is included with the bundle
7.1.19 Warni
ng Beacons
Two rotating warning beacons that are designed for installation onto the pre-wired cab. The kit includes the
beacons, a switch, mounting hardware, and instructions. The beacons are standard equipment for exported
windrowers, and are optional for North America. Fits 2009 and newer machines.
MD #B5582
Instruction MD #169538 is included with the bundle.
7.1.20 Weight Box
To move the windrower without an attached header, attach the weight box to the header lift system. The weight
box allows transporting a header behind the windrower by providing additional weight on the drive wheels.
MD #B5238 – Weight box without harness
40
MD #B5240 – Weight box without harness and concrete.
40
Instruction MD #169280 is included with the bundle.
MD #B5280 – Wiring harness for weight box. Includes hitch pin and wiring for use with slow speed transport. Use
with MD #B5238 and MD #B5240. Required when towing header with SP windrower.
Instruction MD #169278 is included with the bundle.
7.1.21 Windshield Shades
Retra
ctable sun shades for front and rear windows. Attachment hardware is included.
MD #B4
866
Instr
uction MD #169218 is included with the bundle.
39. Weigh t box is required, refer to 7.1.20 Weight Box, page 340
40. Wiring harness MD #B5280 is also required to tow a header. Refer to 7.1.16 Towing Harness, page 339
169890 340 Revision A
