OPERATION
13. Remove clevis pin fro m storage po sition (B) in linkage
and insert in hole (A) to engage float s prin gs. Secure
with hairpin.
Figure 4.99: Header Lift Linkage
14. Disengage safety prop by turning lever (A) downward
to release and lower stop u ntil lever locks into
vertical position.
15. Repeat for opposite s afety prop.
Figure 4.100: Cylinder Stop
CAUTION
Check to be sur e all bystan d ers have cleared t he area.
16. Start engine and activate HEADER DOWN switch on
GSL (A) to lower header fully.
17. Stop engine and remov e key.
Figure 4.101: GSL
169890 140 Revision A
