OPERATOR’S STATION
Display (A) Flashing Alarm Tone Description
LOW HYDRAULIC OIL
X
Continuous loud tone for 5
seconds: if condition not
rectified, single loud tone every
5 minutes
Low hydraulic oil level, header
shuts down automatically if
engaged: HEADER DRIVE switch
must be moved to OFF position
and then to ON position to restart
the header
NO OPERATOR Continuous tone
Operator not detected in seat
with header engaged or out of
N-DETENT: engine shutdown
after 5 seconds
NOT IN PARK
X
Short beep
with each flash
GSL or inte
rlock switches not
closed wit
h key ON / engine O FF
TRANS OIL PRESS
X
Continuous loud tone until oil
pressure is regained
Low transmission charge oil
pressure
TRANS OIL TEMP
X
Ongoing intermittent moderate
tone until temperature is below
acceptable level
Transmission oil temperature
above 221 °F (105°C)
##.# LOW VOLTS
X
short beep every 2 seconds:
flashes every second
Voltage below 11.5
##.# HIGH VOLTS X
short b
eep every 2 seconds:
flashes
every second
Voltag
e above 15.5
169890 69 Revision A
