Remove prints
The high capacity stacker ejects a stack of prints according to your requirements. The high
capacity stacker control shows the filling levels and indicates when an stack eject is prepared.
[113] Location of the high capacity stacker
CAUTION
• Do not open the front cover to remove prints.
• The eject tray of the high capacity stacker can move out automatically.
• Do not walk or stand in the keep clear area of the high capacity stacker.
0
.9 m / 2
.
95 ft
0.
52
m / 1.7 ft
[114] Keep clear area of the high capacity stacker
Eject the stack manually
The time the high capacity stacker ejects a finished stack depends on the configured stacking
behavior.
When you do not want to wait until an automatic stack eject occurs, do the following:
•
Press the eject button once to eject the stack and keep the last set complete. The green
attention light blinks slowly.
Remove prints
Chapter 6 - Job media handling
101
