Oce VarioPrint i Series - Print Process

Print Process
The VarioPrint i-series has a drop-on-demand piezoelectric ink technology. In the print module
the print belt transfers the sheets under the printheads. The nozzles of the printheads eject the ink
drops. The drum of the fixation module dries the printed sheets. The printer cleans the printheads
on a regular base. Therefore, the printhead unit moves to the maintenance position. (
Learn about
printhead maintenance
on page 237)
Transfer of the media sheets during the print process
12
[7] Location of the print process
Location of the print process
1 The print module prints the sheets.
2 The fixation module dries the printed sheets.
6 74 5 123
[8] Transfer of the sheets during the print process
Description
1 The sheets transported on the paper path enter the print module.
2 The print belt uses the suction air technique to flatten the sheets.
4
