Optek C4101 - Dimensions for Additional Housing B19-42 - Plastic - IP66 (Option)

Technical data
- 16 -
optek-converter C4101 Version 07.2009_1.2US, 23.07.2009
www.optek.com
5.2.2 Dimensions for additional housing B19-42 - plastic - IP66 (option)
Fig. 6 Dimensions Control 4000 with additional housing B19-42 - plastic - IP66
CONTROL 4000
CLEAR
9
87
ENTER
0
+/-
4
1
5
2
6
3
120mm [4.72"]90mm [3.54"]
13.4mm [0.53"]
323mm [12.72"]
340mm [13.39"]
353mm [13.9"]
140°
140°
4x M20
8x M16
Ø5.5mm [0.22"]
90mm [3.54"]
237mm [9.33"]
265mm [10.43"]
81mm [3.19"]
287mm [11.3"]
