LB9 User’s Guide 1365/1523
Redistribute - Enables or disables the redistribution for the selected source protocol. It has to be
enabled to be able to configure any of the route redistribution attributes except the 'Distribute List'
field. Default value is Disable.
Command Buttons
Submit - Send the updated configuration to the router. Configuration changes take effect
immediately.
Delete - Delete the entry of the Source Route selected as Configured Source from the list of Sources
configured for OSPF Route Redistribution.
11.6.3.14 Viewing OSPF Route Redistribution Summary Information
This screen displays the OSPF Route Redistribution Configurations.
Non-Configurable Data
Source - The Source Route to be Redistributed by OSPF.
Metric- The Metric of redistributed routes for the given Source Route. Display "Unconfigured" when
not configured.
Metric Type - The OSPF metric types of redistributed routes.
Tag - The tag field in routes redistributed. This field displays the tag if the source was pre-configured,
otherwise 0 and can be modified. The valid values are 0 to 4294967295.
Subnets - Whether the subnetted routes should be redistributed or not.
Distribute List - The Access List that filters the routes to be redistributed by the Destination
Protocol. Display 0 when not configured.
Command Buttons
Refresh - Displays the latest OSPF Route Redistribution Configuration data.
