LB9 User’s Guide 1393/1523
11.6.10.3 Configuring VRRP Secondary Address
Selection Criteria
Secondary Address - he ip address for which data is to be displayed. Create must be selected to
add a secondary address to the interface.
Configurable Data
IP Address - Enter the IP address for the interface. This address must be a member of one of the
subnets currently configured on the interface. This value is readonly once configured.
Non-Configurable Data
Interface - The interface for which data is to be displayed or configured.
Virtual Router ID - The Virtual Router ID for which data is to be displayed or configured.
Primary IP Address - The Primary IP Address of the Virtual Router.
Command Buttons
Submit - Update the switch with the values on this screen. If you want the switch to retain the new
values across a power cycle, you must perform a save.
Delete - Delete the selected secondary IP Address
Cancel - Return to the Virtual Router Configuration screen.
