LB9 User’s Guide 1422/1523
11.7.7.2 Configuring OSPFv3 Area Configuration Page
Selection Criteria
Area ID - Select the area to be configured.
Configurable Data
Import Summary LSAs - Select enable or disable from the pulldown menu. If you select enable
summary LSAs will be imported into areas. Defaults to Enable.
Stub Area Specific Parameters.
Metric Value - Enter the metric value you want applied for the default route advertised into the stub
area. Valid values range from 1 to 65535. This value is applicable only to Stub areas.
NSSA Specific Parameters.
Default Information Originate - The default Route Information. This can also be applied by the CLI
command 'area (area-id) nssa default-info-originate' in the ipv6 router ospf config mode. Valid values
are True or False.
Default Metric - Set the Default Metric value for NSSA. The valid range of values is (1 to 16777214).
Default Metric Type - Select the type of metric specified in the Metric Value field.
ï‚· Comparable Cost - External Type 1 metrics that are comparable to the OSPFv3 metric
ï‚· Non-comparable Cost - External Type 2 metrics that are assumed to be larger than the cost
of the OSPFv3 metric
Translator Role - NSSA Border router's ability to perform NSSA translation of type-7 LSAs into
type-5 LSAs. The valid values are 'Always' and 'Candidate'.
Translator Stability Interval - The number of seconds after an elected translator determines its
services are no longer required, that it should continue to perform its translation duties. The valid
range of values is (0 to 3600). By default it is 40.
No-Redistribute Mode - Enable or Disable the Redistribute Mode into NSSA. By default it is
Enable..
Non-Configurable Data
Area ID - The OSPFv3 area. An Area ID is a 32 bit integer in dotted decimal format that uniquely
identifies the area to which a router interface connects.
