LB9 User’s Guide 279/1523
6.4.1.5 show spanning-tree summary
This command displays spanning tree settings and parameters for the switch. The following details are
displayed on execution of the command.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Spanning Tree Adminmode: Enabled or disabled.
Spanning Tree Forward BPDU: Enabled or disabled
Spanning Tree Version: Version of 802.1 currently supported (IEEE 802.1s, IEEE 802.1w, or IEEE
802.1d) based upon the Force Protocol Version parameter.
BPDU Guard Mode:Enabled or disabled.
BPDU Filter Mode: Enabled or disabled.
BPDU Uplinkfast Mode: Enabled or disabled.
Configuration Name: TConfigured name.
Configuration Revision Level: Configured value.
Configuration Digest Key: Calculated value.
Configuration Format Selector: Configured value.
MST Instances: List of all multiple spanning tree instances configured on the switch.
