UANTA COMPUTER INC.
Layer 2/3/4 Managed Switch
_____________________________________________________________________________
LB9 User’s Guide 283/1523
6.4.2.4 spanning-tree mode
This command sets the Force Protocol Version parameter to a new value. The Force Protocol Version
can be one of the following:
1. stp - ST BPDUs are transmitted rather than MST BPDUs (IEEE 802.1d functionality supported)
2. rstp - RST BPDUs are transmitted rather than MST BPDUs (IEEE 802.1w functionality
supported)
3. mstp - MST BPDUs are transmitted (IEEE 802.1s functionality supported)
Syntax
spanning-tree mode {stp | rstp | mstp}
no spanning-tree mode
no - This command sets the Force Protocol Version parameter to the default value, that is, mstp.
Default Setting
mstp
Command Mode
Global Config
6.4.2.5 spanning-tree forward-time
This command sets the Bridge Forward Delay parameter to a new value for the common and internal
spanning tree. The forward-time value is in seconds within a range of 4 to 30, with the value being
greater than or equal to "(Bridge Max Age / 2) + 1".
Syntax
spanning-tree forward-time <4-30>
no spanning-tree forward-time
<4-30> - forward time value (Range: 4 – 30).
no - This command sets the Bridge Forward Delay parameter for the common and internal spanning
tree to the default value, that is, 15.
Default Setting
15
Command Mode
Global Config
