R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
293User Manual 1175.7068.02 ─ 12
List Evaluation (On/Off) ← List Evaluation ← Spurious Emissions
Activates or deactivates the list evaluation.
Remote command:
CALCulate<n>:PEAKsearch|PSEarch:AUTO on page 758
TRACe<n>:DATA on page 726
Details On/Off ← List Evaluation ← Spurious Emissions
Configures the list contents.
On Displays the whole list contents.
Off Displays only the highest peaks (one peak per range).
Margin ← List Evaluation ← Spurious Emissions
Opens an edit dialog box to enter the margin used for the limit check/peak search.
Only peaks that exceed the limit and are larger than the specified margin are indicated
in the evaluation list.
Remote command:
CALCulate<n>:PEAKsearch|PSEarch:MARGin on page 680
Peaks per Range ← List Evaluation ← Spurious Emissions
Opens an edit dialog box to enter the number of peaks per range that are stored in the
list. Once the selected number of peaks has been reached, the peak search is stopped
in the current range and continued in the next range. The maximum value is 50.
Remote command:
CALCulate<n>:PEAKsearch|PSEarch:SUBRanges on page 759
Show Peaks ← List Evaluation ← Spurious Emissions
In the diagram, marks all peaks with blue squares that have been listed during an
active list evaluation.
Remote command:
CALCulate<n>:PEAKsearch|PSEarch:PSHow on page 758
Save Evaluation List ← List Evaluation ← Spurious Emissions
Opens the "ASCII File Export Name" dialog box and a submenu to save the result in
ASCII format to a specified file and directory.
Remote command:
MMEMory:STORe<n>:LIST on page 777
ASCII File Export ← Save Evaluation List ← List Evaluation ← Spurious Emis-
sions
Saves the evaluation list in ASCII format to a specified file and directory.
Remote command:
MMEMory:STORe<n>:LIST on page 777
