Remote command:
*CAL? on page 915
Show Align Results ← Alignment
Opens a dialog box that displays the correction data of the alignment:
●
Date and time of last correction data record
●
Overall results of correction data record
●
List of found correction values according to function/module
The results are classified as follows:
PASSED calibration successful without any restrictions
CHECK deviation of correction value larger than expected, correction could however be per-
formed
FAILED deviations of correction value too large, no correction was possible. The found cor-
rection data are not applicable.
Remote command:
CALibration:RESult? on page 935
Touch Screen Alignment ← Alignment
Displays a touchscreen alignment dialog.
When the device is delivered, the touchscreen is initially aligned. However, it may
become necessary to adjust the alignment later, e.g. after an image update or after
exchanging a hard disk. If you notice that touching a specific point on the screen does
not achieve the correct response, you may try adjusting the alignment, as well.
Using a finger or any other pointing device, press the 4 markers on the screen.
The touchscreen is aligned according to the executed pointing operations.
General Setup
Opens a submenu for all general settings such as IP address and LAN settings, date
and time, remote control (optional) and measurement display.
Configure Network ← General Setup
Opens the "Network Connections" dialog box to change the LAN settings.
For details, refer to Chapter 11.2.6, "Setting Up a Network (LAN) Connection",
on page 623.
Network Address ← General Setup
Opens a submenu to configure the Internet protocol properties and the computer
name.
Computer Name ← Network Address ← General Setup
Opens an edit dialog box to enter the computer name via the keypad. The naming con-
ventions of Windows apply. If too many characters and/or numbers are entered, a mes-
sage is displayed in the status line. For step-by-step instructions, refer to Chap-
ter 11.2.6.3, "Using Computer Names", on page 628.
