R&S ESR Series User Manual

Remote Control
R&S
®
ESR
661User Manual 1175.7068.02 ─ 12
Example:
CALC:DELT2:SGR:SAR VIS
CALC:DELT2:SGR:XY:MAX
Activates and positions delta marker 2 on the peak level in the
visible Spectrogram.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:XY:MINimum[:PEAK]
This command positions the specified delta marker on the current minimum level of the
spectrogram. The possible position depends on the deltamarker search area.
The command is available for the spectrogram.
For more information, see CALCulate<n>:DELTamarker<m>:SGRam:SARea
on page 660.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT3:SGR:SAR VIS
CALC:DELT3:SGR:XY:MIN
Activates and positions delta marker 3 on the minimum level in
the visible Spectrogram.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:ABOVe
This command positions the specified delta marker on the next peak level of the verti-
cal axis. The search includes only frames above the current marker position. It does
not change the horizontal position of the delta marker.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT2:SGR:Y:MAX
Activates and positions delta marker 2 on the peak level of the y-
axis.
CALC:DELT2:SGR:Y:MAX:ABOV
Positions delta marker 2 on the next higher level found in the
diagram area above the current marker position.
Usage: Event
Remote Commands in Receiver Mode
