R&S ESR Series User Manual

Remote Control
R&S
®
ESR
660User Manual 1175.7068.02 ─ 12
<time> (if time stamp is on)
Defines the distance of the deltamarker in seconds and in rela-
tion to the position of marker 1. The reference is the time stamp
of marker 1.
Example:
CALC:DELT4:SGR:FRAM -20
Sets fourth deltamarker 20 frames below marker 1.
CALC:DELT4:SGR:FRAM 2 s
Sets fourth deltamarker 2 seconds above the position of marker
1.
CALCulate<n>:DELTamarker<m>:SGRam:SARea <SearchArea>
This command defines the deltamarker search area.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Parameters:
<SearchArea> VISible
Performs a search in the visible frames.
Note that VISible is ignored if Spectrogram is not visible for any
reason (e.g. if the Spectrum Analyzer is in full screen mode or
display update is inactive).
MEMory
Performs a search over all frames in the memory.
*RST: VISible
Example:
CALC:DELT:SGR:SAR MEM
Performs a search over all frames in the memory.
CALCulate<n>:DELTamarker<m>:SGRam:XY:MAXimum[:PEAK]
This command positions the specified delta marker on the current peak level of the
spectrogram. The possible position depends on the deltamarker search area.
The command is available for the spectrogram.
For more information, see CALCulate<n>:DELTamarker<m>:SGRam:SARea
on page 660.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Remote Commands in Receiver Mode
