R&S ESR Series User Manual

Remote Control
R&S
®
ESR
698User Manual 1175.7068.02 ─ 12
Suffix:
<n>
.
Selects the measurement window.
<m> 1
irrelevant
Parameters:
<State> ON | OFF
*RST: OFF
Example:
CALC:DELT:LINK ON
Manual operation: See "Link Mkr1 and Delta1" on page 408
CALCulate<n>:DELTamarker<m>:MAXimum:LEFT
This command positions the delta marker to the next smaller trace maximum on the left
of the current value (i.e. descending X values). The corresponding delta marker is acti-
vated first, if necessary.
If no next higher minimum value is found on the trace (level spacing to adjacent values
< peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:DELT:MAX:LEFT
Sets delta marker 1 to the next smaller maximum value to the
left of the current value.
Manual operation: See "Next Mode" on page 205
CALCulate<n>:DELTamarker<m>:MAXimum:NEXT
This command positions the delta marker to the next smaller trace maximum. The cor-
responding delta marker is activated first, if necessary.
If no next higher minimum value is found on the trace (level spacing to adjacent values
< peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:DELT2:MAX:NEXT
Sets delta marker 2 to the next smaller maximum value.
Manual operation: See "Next Peak" on page 205
See "Next Mode" on page 205
Remote Commands in Receiver Mode
