R&S ESR Series User Manual

Remote Control
R&S
®
ESR
712User Manual 1175.7068.02 ─ 12
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Margin> Numeric value that defines the margin.
In spectrum mode, the unit is always dB.
*RST: 0
Example:
CALC:LIM:LOW:MARG 10dB
CALCulate<n>:LIMit<k>:LOWer:MODE
<Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Mode> ABSolute
Limit line is defined by absolute physical values. The unit is vari-
able.
RELative
Limit line is defined by values relative to the reference level (dB).
*RST: ABSolute
Example:
CALC:LIM:LOW:MODE REL
Defines the y-axis of limit line 2 as relative scaled.
Manual operation: See "Edit Name" on page 210
CALCulate<n>:LIMit<k>:LOWer:OFFSet <Offset>
This command defines an offset for a complete lower limit line.
Compared to shifting the limit line, an offset does not actually change the limit line defi-
nition points.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Offset> Numeric value that defines the offset.
*RST: 0
Remote Commands in Receiver Mode
