Example:
CALC:LIM2:LOW:OFFS 3dB
Shifts limit line 2 by 3 dB upwards.
Manual operation: See "Y Offset" on page 212
CALCulate<n>:LIMit<k>:LOWer:SHIFt <Distance>
This command moves a complete lower limit line vertically.
Compared to defining an offset, this command actually changes the limit line definition
points by the value you define.
Suffix:
<n>
.
irrelevant
<k> Selects the limit line.
Parameters:
<Distance> Numeric value that defines the distance of the shift.
The unit depends on CALCulate<n>:LIMit<k>:UNIT
on page 708.
Example:
CALC:LIM3:LOW:SHIF 20DB
Shifts all Y values of limit line 3 by 20 dB.
CALCulate<n>:LIMit<k>:LOWer:SPACing <InterpolType>
This command selects linear or logarithmic interpolation for the lower limit line.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<InterpolType> LINear | LOGarithmic
*RST: LIN
Example:
CALC:LIM:LOW:SPAC LIN
CALCulate<n>:LIMit<k>:LOWer:STATe <State>
This command turns a lower limit line on and off.
Before you can use this command, you have to select a limit line with
CALCulate<n>:LIMit<k>:NAME.
The limit check is turned on separately. For more information see "Using Frequency
Lines" on page 860.
Suffix:
<n>
.
irrelevant
Remote Commands in Receiver Mode
