R&S ESR Series User Manual

Remote Control
R&S
®
ESR
714User Manual 1175.7068.02 ─ 12
<k> 1...8
Selects the limit line.
Parameters:
<State> ON | OFF
*RST: OFF
Example:
CALC:LIM4:LOW:STAT ON
Switches on limit line 4 (lower limit).
CALCulate<n>:LIMit<k>:LOWer:THReshold <Threshold>
This command defines a threshold for relative limit lines.
The R&S ESR uses the threshold for the limit check, if the limit line violates the thresh-
old.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Threshold> Numeric value that defines the threshold.
The unit depends on CALCulate<n>:LIMit<k>:UNIT.
*RST: -200 dBm
Example:
CALC:LIM2:LOW:THR -35DBM
Defines an absolute threshold value for limit line 2.
CALCulate<n>:LIMit<k>:UPPer[:DATA] <LimitLinePoints>
This command defines the vertical definition points of an upper limit line.
If the measured values exceed the UPPer limit line, the limit is violated.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<LimitLinePoints> Variable number of x-axis values.
Note that the number of horizontal values has to be the same as
the number of vertical values set with CALCulate<n>:
LIMit<k>:CONTrol[:DATA]. If not, the R&S ESR either adds
missing values or ignores surplus values.
The unit depends on CALCulate<n>:LIMit<k>:UNIT.
*RST: (LIMit:STATe is set to OFF)
Remote Commands in Receiver Mode
