Example:
CALC:LIM2:UPP -10,0,0,-10,-5
Defines 5 upper limit values for limit line 2 in the preset unit.
CALC:LIM2:UPP?
Outputs the upper limit values for limit line 2 separated by a
comma.
Manual operation: See "Edit Value" on page 211
CALCulate<n>:LIMit<k>:UPPer:MARGin <Margin>
This command defines an area around a upper limit line where limit check violations
are still tolerated.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Margin> Numeric value that defines the margin.
In spectrum mode, the unit is always dB.
*RST: 0
Example:
CALC:LIM2:UPP:MARG 10dB
Defines the margin of limit line 2 to 10 dB below the limit value.
CALCulate<n>:LIMit<k>:UPPer:MODE <Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
irrelevant
<k> 1...8
Selects the limit line.
Parameters:
<Mode> ABSolute
Limit line is defined by absolute physical values. The unit is vari-
able.
RELative
Limit line is defined by values relative to the reference level (dB).
*RST: ABSolute
Example:
CALC:LIM2:UPP:MODE REL
Defines the y-axis of limit line 2 as relative scaled.
CALCulate<n>:LIMit<k>:UPPer:OFFSet <Offset>
This command defines an offset for a complete upper limit line.
