Remote Control
R&S
®
ESR
709User Manual 1175.7068.02 ─ 12
CALCulate<n>:LIMit<k>:CONTrol[:DATA] <LimitLinePoints>
This command defines the horizontal definition points of a lower limit line.
Suffix:
<n>
.
Selects the measurement window.
<k> 1...8
Selects the limit line.
Parameters:
<LimitLinePoints> Variable number of x-axis values.
Note that the number of horizontal values has to be the same as
the number of vertical values set with CALCulate<n>:
LIMit<k>:LOWer[:DATA] or CALCulate<n>:LIMit<k>:
UPPer[:DATA]. If not, the R&S ESR either adds missing val-
ues or ignores surplus values.
The unit is Hz or s, depending on CALCulate<n>:LIMit<k>:
CONTrol:DOMain.
*RST: - (CALC:LIM is set to OFF)
Example:
CALC:LIM2:CONT 1 MHz,30 MHz,100 MHz,300 MHz,1
GHz
Defines 5 reference values for the x-axis of limit line 2.
CALC:LIM2:CONT?
Outputs the reference values for the x-axis of limit line 2 separa-
ted by a comma.
Manual operation: See "Edit Value" on page 211
CALCulate<n>:LIMit<k>:CONTrol:DOMain <SpanSetting>
This command selects the domain of the limit line.
Suffix:
<n>
.
Selects the measurement window.
<k> 1...8
Selects the limit line.
Parameters:
<SpanSetting> FREQuency | TIME
*RST: FREQuency
Example:
CALC:LIM2:CONT:DOM TIME
Defines zero span for the x-axis of limit line 2.
CALCulate<n>:LIMit<k>:CONTrol:MODE <Mode>
This command selects the horizontal limit line scaling.
Suffix:
<n>
.
Selects the measurement window.
Remote Commands in Receiver Mode
