R&S ESR Series User Manual

Remote Control
R&S
®
ESR
797User Manual 1175.7068.02 ─ 12
y-axis upper limit: 1.0
y-axis lower limit: 1E-6
Suffix:
<n>
.
irrelevant
Example:
CALC:STAT:PRES
Resets the scaling for statistical functions
Manual operation: See "Default Settings" on page 319
CALCulate<n>:STATistics:SCALe:AUTO ONCE
This command optimizes the level setting of the instrument depending on the mea-
sured peak power, in order to obtain maximum instrument sensitivity.
To obtain maximum resolution, the level range is set as a function of the measured
spacing between peak power and the minimum power for the APD measurement and
of the spacing between peak power and mean power for the CCDF measurement. In
addition, the probability scale for the number of test points is adapted.
Subsequent commands have to be synchronized with *WAI, *OPC or *OPC? to the
end of the auto range process which would otherwise be aborted.
Suffix:
<n>
.
irrelevant
Example:
CALC:STAT:SCAL:AUTO ONCE;*WAI
Adapts the level setting for statistical measurements.
Manual operation: See "Adjust Settings" on page 320
CALCulate<n>:STATistics:SCALe:X:RANGe <Value>
This command defines the level range for the x-axis of the measurement diagram. The
setting is identical to the level range setting defined with the DISPlay[:
WINDow<n>]:TRACe<t>:Y[:SCALe] command.
Suffix:
<n>
.
irrelevant
Parameters:
<Value> 10dB to 200dB
*RST: 100dB
Example:
CALC:STAT:SCAL:X:RANG 20dB
Manual operation: See "x-Axis Range" on page 317
Remote Commands in Spectrum Analyzer Mode
