R&S ESR Series User Manual

Remote Control
R&S
®
ESR
844User Manual 1175.7068.02 ─ 12
CALCulate<n>:UNIT:POWer <Unit>
This command selects the unit of the y-axis.
The unit applies to all measurement windows.
Suffix:
<n>
.
irrelevant
Parameters:
<Unit> DBM | V | A | W | DBPW | WATT | DBUV | DBMV | VOLT |
DBUA | AMPere
*RST: dBm
Example:
CALC:UNIT:POW DBM
Sets the power unit to dBm.
Manual operation: See "Unit" on page 354
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe] <Range>
This command defines the display range of the y-axis with logarithmic scaling.
The command works only for a logarithmic scaling. You can select the scaling with
DISPlay[:WINDow<n>]:TRACe<t>:Y:SPACing on page 668.
Suffix:
<n>
.
window; For applications that do not have more than 1 measure-
ment window, the suffix <n> is irrelevant.
<t> irrelevant
Parameters:
<Range> Range: 10 to 200
*RST: 100
Default unit: dB
Example:
DISP:TRAC:Y 110dB
Manual operation: See "Grid Range / Grid Min Level" on page 183
See "Range Log 100 dB" on page 317
See "Range Log 50 dB" on page 317
See "Range Log 10 dB" on page 318
See "Range Log 5 dB" on page 318
See "Range Log 1 dB" on page 318
See "Range Log Manual" on page 318
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:MODE <Mode>
This command selects the type of scaling of the y-axis.
When SYSTem:DISPlay:UPDate is turned off, this command has no immediate
effect on the screen.
Remote Commands in Spectrum Analyzer Mode
