Remote Control
R&S
®
ESR
888User Manual 1175.7068.02 ─ 12
TRACe<n>:IQ:DATA:MEMory?........................................................................................895
TRACe<n>:IQ:EGATe.....................................................................................................896
TRACe<n>:IQ:EGATe:GAP............................................................................................. 896
TRACe<n>:IQ:EGATe:LENGth........................................................................................ 897
TRACe<n>:IQ:EGATe:NOFgateperiods............................................................................ 897
TRACe<n>:IQ:EGATe:TYPE........................................................................................... 897
TRACe<n>:IQ:EVAL.......................................................................................................898
TRACe<n>:IQ[:STATe]....................................................................................................898
TRACe<n>:IQ:TPISample?.............................................................................................899
CALCulate<n>:FORMat <Format>
This command defines the display type of the IQ data.
Suffix:
<n>
.
irrelevant
Parameters:
<Format> RIMag
IQ data
MAGNitude
Magnitude
FREQuency
Spectrum
VECTor
IQ-Vector
Manual operation: See "I/Q Analyzer" on page 459
See "Display Config" on page 460
CALCulate<n>:MARKer<m>:SEARch <MarkRealImag>
This command selects the trace type a marker search is performed on.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Parameters:
<MarkRealImag> REAL
Marker search functions are performed on the real trace of the
"I/Q" measurement.
IMAG
Marker search functions are performed on the imaginary trace of
the "I/Q" measurement.
MAGN
Marker search functions are performed on the magnitude of the I
and Q data.
*RST: REAL
Remote Commands in I/Q Analyzer Mode
