OPTIONAL EQUIPMENT
Cycle
EM Regular PM Remarks
Item
ARDF (A548) 80k 160k 240k (Number of originals)
Transport belt C R R R Wipe with a damp cloth.
Separation belt C R R R Water
Separation roller C R R R Wipe with Alcohol.
Registration/size/paper
exit sensors
C C C R Clean with a blower brush.
PAPER FEED BANK (A549/A550) 120k 240k 360k (Number of copies)
Paper feed roller C C R C Water, replace these rollers as
a set.
Pick-up roller C C R C
Separation roller C C R C
Relay roller C C C Alcohol or water
Bottom Plate Pad C R R R Water
Relay clutch I I I Replace every 1500 k copies
Paper feed clutch I I I Replace if necessary
Drive belts I I I Replace if necessary
SORTER (A555)
Transport rollers I Clean with alcohol if stained.
Relay rollers I Clean with alcohol if stained.
Bins I Clean with alcohol if stained.
Entrance/bin/staple
sensors
I Clean with alcohol if stained.
Bin slider I Apply oil if abnormal sound is
heard (grease G501).
Shaft bearings I Apply oil if abnormal sound is
heard (silicone oil or LAUNA
oil).
Staple I
Service
Tables
REGULAR PM TABLE
SM 4-41 A166/A187/A189
