OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 805
7 VOIP WLAN Adjusts sensitivity from VOIP C.O. Tx to WLAN Rx
0 SVM DGP Adjusts sensitivity from SVM Tx to digital phone Rx
1 SVM SLT Adjusts sensitivity from SVM Tx to normal station Rx
2 SVM ATRK Adjusts sensitivity from SVM Tx to analog C.O. Rx
3 SVM DTRK Adjusts sensitivity from SVM Tx to digital C.O. Rx
4 SVM ITP Adjusts sensitivity from SVM Tx to ITP Rx
5 SVM VOIP Adjusts sensitivity from SVM Tx to VOIP C.O. Rx
6 SVM SVM Adjusts sensitivity from SVM Tx to SVM Rx
6
7 SVM WLAN Adjusts sensitivity from SVM Tx to WLAN Rx
0 WLAN DGP Adjusts sensitivity from WLAN Tx to digital phone Rx
1 WLAN SLT Adjusts sensitivity from WLAN Tx to normal station Rx
2 WLAN ATRK Adjusts sensitivity from WLAN Tx to analog C.O. Rx
3 WLAN DTRK Adjusts sensitivity from WLAN Tx to digital C.O. Rx
4 WLAN ITP Adjusts sensitivity from WLAN Tx to ITP Rx
5 WLAN VOIP Adjusts sensitivity from WLAN Tx to VOIP C.O. Rx
6 WLAN SVM Adjusts sensitivity from WLAN Tx to SVM Rx
7
7 WLAN WLAN Adjusts sensitivity from WLAN Tx to WLAN Rx
There are four types of tone sensitivity adjustment as shown below:
0 +0. 0 No adjustment.
1 +1. 9 Up 1. 9 dB
2 - 6. 0 Down 6. 0 dB
3 - 2. 5 Down 2. 5 dB
3. R2 LEVEL CONTROL : Adjust R2MFC signal detection
0. THRESHOLD
1. TX LEVEL
2. RX LEVEL
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
