Page #223 background imageLoading...
Page #223 background image
223
The setting items are as follows:
Calibrate
Adjust the media sensor.
Head Check
Check if there is a broken element of the print head.
Head Check Mode
Set the mode for head check.
Appears if you have selected [All] or [Barcode] in the [Head Check] menu.
Every Page
Set the interval for head check.
Appears if you have selected [Every Page] in the [Head Check Mode] menu.
Check Media Size
Enable or disable media size check.
Appears if you have selected [Gap] or [I-Mark] in the [Sensor Type] menu.
Adjustments
Correct the offset value, print position and print darkness.
Start Online
Set whether to power on the product in Online mode.
Feed After Error
Set whether to automatically feed the media when recovering from an error.
Feed At Power On
Set whether to automatically feed the media when the product is powered on.
Finisher Feed
Set the length to feed after printing.
Paper End
Select the sensor for sensing the paper end.
Head Base Position
Set the edge position for printing.
Prioritize
For product settings, set whether to prioritize the settings that are done through the product or
through commands.
Reprint
Enable or disable the reprint function.
Print End Position
Adjust the media stop position or cut position when [Sensor Type] is set to [None].
