H.12
SEL-351A Relay Instruction Manual Date Code 20080213
Distributed Network Protocol
Object Table
40 0 Analog Output Status—All Vari-
ations
1 0,1,6,7,8
40 1 32-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
40 2
e
16-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
41 0 Analog Output Block—All Vari-
ations
41 1 32-Bit Analog Output Block 3,4,5,6 17,28 129 echo of
request
41 2 16-Bit Analog Output Block 3,4,5,6 17,28 129 echo of
request
50 0 Time and Date—All Variations
50 1 Time and Date 1,2 7,8
index = 0
129 07,
quantity
=1
50 2 Time and Date with Interval
51 0 Time and Date CTO—All Varia-
tions
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date
CTO
07,
quantity
=1
52 0 Time Delay—All Variations
52 1 Time Delay Coarse
52 2 Time Delay Fine 129 07,
quantity
=1
60 0 All Classes of Data 1,20,21 6
60 1 Class 0 Data 1 6
60 2 Class 1 Data 1,20,21 6,7,8
60 3 Class 2 Data 1,20,21 6,7,8
60 4 Class 3 Data 1,20,21 6,7,8
70 1 File Identifier
80 1 Internal Indications 2 0,1
index = 7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object
Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
Table H.5 SEL-351A DNP Object Table (Sheet 4 of 5)
Object Request
a
Response
b
Obj Var Description
Func.
Codes
c
Qual.
Codes
d
Func.
Codes
c
Qual.
Codes
d
