Siemens HiPath 1120 Service Manual

Modules
3-114 Service Manual
Interconnect cables
Figure 3-48 V.24 adapter cable connection system
V.24 adapter cable signals
Table 3-40 V.24 adapter cable signals
Pin Signal
CTS Clear To Send
GND Ground
RTS Request to send
RxD Receive Data
TxD Transmit Data
Length approx 6"
6-pin SIC mini-DIN
connector
9-pin female
SubD connector
Free 9
CTS 8
RTS 7
Free 6
1
2
34
56
RTS
CTS
GND
TxD
RxD
VCC
5 GND
4 Free
3 TxD
2 RxD
1 Free
Length 102 "
Level adaptation on
the cable and
Galvanic Insulation
Adapter
MB
PC
Printer
Modem
