Siemens HiPath 1120 Service Manual

Service Manual
3-49
Modules
List of modules
– Interconnect cable between batteries
(BBU)
C39195-A7944-B49
Ferrite for power cable C39022-Z7000-C7
Interconnect cable between PSU-batteries
(BBU)
C39195-A7700-B9
Interconnect cable for HiPath 1190 power
supply (BBU)
C39195-A7700-B10
Vshare cable for HiPath 1190 (BBU) C39195-A7700-B8
Power Supply Unit (PSU)
HiPath 1150 S30122-K7642-X10-* (IM, AUS and IND)
S30122-K7642-X30-* (RSA)
With BBU (Battery Backup Unit)
S30817-U853-A400-* (B AUS)
S30817-U853-B401-* (IM )
S30817-U853-B464-* (IND)
HiPath 1190 S30122-K7642-X200-* (IM, AUS and IND)
S30122-K7642-X300-* (RSA)
Full with BBU (Battery Backup Unit)
S30777-U770-E400-* (AUS)
S30777-U770-E401-* (IM )
S30777-U770-E464-* (IND)
Medium with BBU (Battery Backup Unit)
S30777-U770-F400-* (AUS)
S30777-U770-F401-* (IM )
S30777-U770-F464-* (IND)
HiPath 1190R S30122-K7642-X200-* (IM, AUS and IND)
S30122-K7642-X300-* (RSA)
Full with BBU (Battery Backup Unit)
S30777-U770-G400-* (AUS)
S30777-U770-G401-* (IM )
S30777-U770-G464-* (IND)
Medium with BBU (Battery Backup Unit)
S30777-U770-H400-* (AUS)
S30777-U770-H401-* (IM )
S30777-U770-H464-* (IND)
Expansion Kit with BBU (Battery Backup Unit)
HiPath 1150
Power supply and cables
S30817-H853-B401-*
Module / component Reference
