Service Manual
3-89
Modules
Optional modules (MO)
HiPath 1120/1150/1190/1190R
Interfaces
Figure 3-29 HiPath 1120/1150/1190/1190R EVM module
Connector assignments
Table 3-29 EVM HiPath 1120/1150/1190/1190R module Connector
X1 Connector
Connects to MB through a pin Connector
