Siemens HiPath 1120 Service Manual

Configuring the system specifically for the client
6-230 Service Manual
Table of the System’s Programming Codes
6.2.12 Digital trunk settings
Programmed
Functions
Code Intermediate data Data to be
programmed
Completing
data entry
Default
S
0
Ports 062 Position/slot:
HiPath 1120: 02
HiPath 1150: 03
HiPath 1190: 01 and 11
1 - External line and exten-
sion
2 - External line
3 - Extension
# instead of
slot position
1 - external
line and
extension
Operation Mode
for S
0 Line
*
190 01, 02, 03 or 11
+
00 to 01 (HiPath 1120 - 00 PP or
PMP only)
00 to 04 (HiPath 1150)
00 to 04 (HiPath 1190)
1 - Point-to-point connec-
tion (PP)
2 - Point-to-Multipoint
connection (PMP)
3 - S
0 Bus line
# instead of
slot position
1 - First port
3 - All other
ports
Symmetric/Asym-
metric Call
074 01, 02, 03 or 11
+
00 to 01 (HiPath 1120 - 00 PP or
PMP only)
00 to 04 (HiPath 1150)
00 to 04 (HiPath 1190)
∗ - Asymmetric
# - Symmetric
Automatic # - Symmet-
ric
No ACK Setup for
S
0 Line
075 01, 02, 03 or 11
+
00 to 01 (HiPath 1120 - 00 PP or
PMP only)
00 to 04 (HiPath 1150)
00 to 04 (HiPath 1190)
∗ - to enable
# - to disable
Automatic Depending
on the coun-
try
Notify 076 01, 02, 03 or 11
+
00 to 01 (HiPath 1120 - 00 PP or
PMP only)
00 to 04 (HiPath 1150)
00 to 04 (HiPath 1190)
∗ - to enable
# - to disable
Automatic Depending
on the coun-
try
Automatic Keypad 077
∗ - to enable
# - to disable
Automatic # - to disable
Assignment of a
digital line to an
MSN
078 Position: 001 to 140 external line or
∗ - to delete
# instead of
slot position
All assigned
lines
External line prefix 189 1 - National
2 - International
Line prefix (up to 5 digits) # instead of
the digit or
automatic
None
External number
registration
191 Position: 001 to 140 DID final digits (up to 20
digits)
# instead of
slot position
None
Assignment of an
MSN to attendants
192 Position: 001 to 140
+
1 - Day service
2 - Night service
3 - Day service, second attendant
4 - Night service, second attendant
Extension, Call Group (CG,
HG or UCD with up to 10
extensions per group) or
EVM Virtual Port (744 to
747).
∗ - to delete
# instead of
extension
None
