Modules
Expansion modules (EB)
Table 3-21 Display indications of TME1 module (S2 access)
3.5.5 U
P0/E
module and CTR U
P0/E
module
Introduction
With these modules you can connect U
P0/E
telephones (optiPoint 500) to a HiPath 1150/1190
via 8, 4 or 2 U
P0/E
interfaces, and to a HiPath 1120 system via 4 or 2 U
P0/E
interfaces (see
“System expansion limitations” on page 2-30).
3.5.5.1 U
P0/E
module
HiPath 1120
Interfaces
Figure 3-20 U
P0/E
module HiPath 1120
Continuous Network link operational.
Continuous Link with mainboard operational.
CTR-U module installation is required.
P0/E
no in MB module (see “Installing a CTR-
UP0/E module” on page 4-158 )
Display Reading Meaning
