Siemens HiPath 1120 Service Manual

Modules
3-90 Service Manual
Optional modules (MO)
3.6.3 CD 16 module
Introduction
● This is an expansion module to provide support for over 16 CD interfaces on the HiPath
1190/1190R and for connecting more than 16 KS type system telephones.
The CD 16 module has a dedicated slot for burning CDs.
CD 16 Interfaces
Figure 3-30 CD 16 module
Note: CD interfaces on a CD 16 module are installed subsequently to CD interfaces on the MB
module.
7
When a UP0/E module is connected to the HiPath 1190/1190R, the CD 16 mod-
ule is disabled.
