Siemens HiPath 1120 Service Manual

Installation
4-168 Service Manual
Installing the power supply
Figure 4-37 Installing the PSU with BBU in the HiPath 1190/1190R
Interconnect cable
with batteries
Batteries
2 x 12V
(in series)
Interconnect cable
PSU - Cable for
Protective cover
AC input sockets
Vshare cable
Interconnect cable
Interconnect cable between
PSU’s
Interconnect cable
PSU - Cable for
connection
with batteries
between
PSU’s
batteries
connection with the
20 mm at most
Ferrites
