Service Manual
7-281
Operation
System programming mode using a PC
Connections:
7.2.1 Local Connection
7.2.1.1 V.24 Serial Interface
For this option, first install the HiPath 1100 applications then set the CommServer.
Procedure:
1. Check that the HiPath 1100 system is ON
2. Insert the HiPath 1100 CD in the CD drive
If Auto-Run is not configured, go to the Windows Start menu, click Run and then select the
Browse button in the dialog box. Open the SETUP.EXE file on the CD drive.
3. In the Setup window, select the language you want to use
4. A window will appear where you can select the software to be installed
5. Select the software components you wish to install and install them. For programming the
HiPath 1100 system, the following applications must be installed:
● HiPath 1100 Manager
● CommServer (installs automatically).
6. After each component is installed, a message is displayed indicating that the installation
was completed successfully. Click "Next" every time it appears
7. Click "Finish" to close the installation window. This completes the software installation.
Restart the PC if Windows requires this.
Connections PC <--> HiPath 1100
Page
Local Connection
7-293
With a V.24 Serial Interface 7-293
With a USB Interface 7-281
With the LAN interface module 7-283
With optiPoint 7-287
Remote or local connections
7-333
With an Analog modem 7-290
With an ISDN modem via S
0
module
7-293
