Siemens HiPath 1120 - Page 144

Installation
4-144 Service Manual
Installing modules
Table 4-3 Slot / type of module on HiPath 1190/1190R systems
Note: The CD module and the CPU have fixed slots on the HiPath 1190/1190R systems. They
can be seen on the Modules Latch (Figure 4-18 on page 4-141).
Slots 16 and 17
Type of module
Position 18
Type of module
Expansion modules
EB 010
Expansion modules
EB 010 EB 012
EB 202 EB 202
EB 206 EB 206
EB 200 EB 210
EB 400 EB 200
EB 800 EB 400
EB 800
Slots 19 and 20
Type of module
Expansion modules
EB 010
EB 202
EB 206
EB 200
EB 400
EB 800
